Name: High Efficiency 3 Port Optical Circulator Low Insertion Loss for 1310nm or 1550nm Applications
Brand: Guangdong Huajiayu Technology Co., Ltd
SKU: 3 Ports Optical Circulator
Price: 500.00 USD
Availability: InStock

Home > products > Optical Circulator >

High Efficiency 3 Port Optical Circulator Low Insertion Loss for 1310nm or 1550nm Applications

High Efficiency Optical Circulator

Low Insertion Loss Optical Circulator

3 Port Optical Circulator

Place of Origin:

China

Brand Name:

HJY

Certification:

CE, ROHS, FCC ISO9001

Model Number:

3 Ports Optical Circulator

Request A Quote

Product Details

Insertion Loss:

≤0.8dB

Pdl:

≤0.2dB

Storage Temperature:

-40℃ To +85℃

Operating Temperature:

-5℃ To +70℃

Connector Type:

FC, SC, ST, LC, Or Custom

Port:

1x2 Or 2x2

Wavelength:

1310nm Or 1550nm

Configuration:

3port, 4port

Highlight:

High Efficiency Optical Circulator

Low Insertion Loss Optical Circulator

3 Port Optical Circulator

Payment & Shipping Terms

Minimum Order Quantity

10 pcs

Price

1~999

Packaging Details

Roll, Neutrial Packing or with OEM LOGO

Delivery Time

5~8 working days

Payment Terms

T/T,Western Union,L/C

Supply Ability

100,000 pcs

Multi Scenario 3 Port Circulator 1310nm or 1550nm High Power Handling 30dBm Lab Industrial Hybrid Design

Get Best Price

Video

Broad Spectrum 3 Port Optical Circulator 1310nm or 1550nm AR Coated Interfaces Data Center Grade Reliability

Get Best Price

Video

Ultra Low Insertion Loss Tri Port Circulator 1310 or 1550nm Wide Operating Bandwidth Laser and Telecom Compatible

Get Best Price

Video

Industrial Temp 3 Port Fiber Circulator 1310 or 1550nm Polarization Insensitive Optics DWDM EDFA System Ready

Get Best Price

8613556217949

francesgdut@gmail.com

Contact Now

Product Description

High Efficiency 3 Port Optical Circulator - Low Insertion Loss for 1310nm/1550nm Applications‌

‌Premium Performance for Demanding Optical Networks‌

Our ‌High Efficiency 3 Port Optical Circulator‌ delivers ‌exceptional signal routing performance‌ for ‌1310nm and 1550nm wavelength applications‌. Engineered with ‌ultra-low insertion loss (<0.5dB)‌ and ‌high isolation (>50dB)‌, this circulator ensures ‌minimal signal degradation‌ in even the most demanding optical communication systems.

‌Key Features & Benefits:‌
✔ ‌Industry-Leading Efficiency‌ - Optimized design maximizes signal transmission
✔ ‌Ultra-Low Insertion Loss‌ (<0.5dB) - Minimizes power loss for clearer signals
✔ ‌Dual Wavelength Compatibility‌ - Perfect for both 1310nm & 1550nm applications
✔ ‌High Isolation Performance‌ (>50dB) - Reduces interference and crosstalk
✔ ‌Compact & Durable Construction‌ - Ideal for space-constrained installations
✔ ‌Wide Temperature Range‌ (-40°C to +85°C) - Reliable operation in harsh environments

‌Ideal Applications Include:‌

* DWDM/CWDM Systems‌ - Efficient channel routing

* Fiber Optic Amplifiers‌ - EDFA/Raman applications
* Telecommunication Networks‌ - Long-haul and metro systems
* Data Center Interconnects‌ - High-speed data transmission
* LIDAR & Sensing Systems‌ - Precision optical routing

‌Why Choose Our Optical Circulator?‌

* Proven Reliability‌ - Rigorously tested for long-term performance
* Plug-and-Play Installation‌ - Easy integration into existing systems
* Superior Optical Performance‌ - Backed by stringent quality control
* Cost-Effective Solution‌ - Delivers premium quality at competitive pricing

‌Technical Specifications:‌
* ‌Insertion Loss:‌ <0.5dB typical
* Isolation:‌ >50dB
* Return Loss:‌ >50dB
* PDL:‌ <0.1dB
* Power Handling:‌ 300mW
* Operating Temperature:‌ -40°C to +85°C

‌Upgrade Your Optical Network Today!‌
Experience ‌unmatched signal integrity‌ and ‌reliable performance‌ with our High Efficiency 3 Port Optical Circulator. Contact us for volume pricing and custom configuration options.

HJY's Optical Circulator is a non-reciprocal passive device that directs light signals sequentially between ports (e.g., Port 1→2, Port 2→3, Port 3→1). It utilizes Faraday rotation and birefringent crystals to enable bidirectional optical routing with minimal loss. Key features include low insertion loss, high isolation, and compact design, making it ideal for telecommunications, fiber sensing, and dense wavelength-division multiplexing (DWDM) systems.

Category	Types	Key Features
Port Configuration	3-Port	Standard unidirectional flow (Port 1→2→3→1)
	4-Port	Extended routing for complex network topologies
Application Grade	Telecommunication-Grade	High reliability for long-haul networks
	Industrial-Grade	Ruggedized for harsh environments (e.g., sensing)

Parameter		1310	1550	C&L	1610
Operation Wavelength (nm)		1280~1340	1520~1580	1525 ～ 1610	1580~ 1660
Configuration		Port1 to Port 2； Port2 to Port3
Grade		P
Insertion Loss(dB)	Typical	0.6
	Maximum	0.8
Channel Max. Isolation (dB)		50
Channel Min. Isolation(dB)		40
Directivity( (dB)		50
PDL (dB)		<0.15
PMD(ps)		<0.1
RL (dB)		>50
Bandwidth (nm)		+/-30
Max Operating Power (mW)		500
Operating Temperature (℃)		0~+70
Storage Temperature (℃)		-40~+85
Fiber type		Corning SMF-28e
Dimension (mm)		1． Φ5.5xL50 ( bare fiber or 900um Loose tube
		2. L90xW20xH9.5( 2.0mm or 3.0mm Cable)
